| Parameter | US | EU | ||||||
| Product Power | 120kW | 180kW | 240kW | 120kW | 180kW | 240kW | ||
| Input Voltage | 3-phase 480V AC (+10%/-15%) 60Hz | 3-phase 400V AC (+10%/-10%) 50Hz | ||||||
| Input Current | 155A | 233A | 310A | 186A | 279A | 372A | ||
| Output Voltage | 200-1000VDC | |||||||
| Max Output Current | 200A | 250A | ||||||
| Number of Outputs | 2 | |||||||
| Interface Type | CCS1, NACS | CCS2 | ||||||
| Input Wire Harness | 3P+PE, 3P+N+PE | |||||||
| Protection Level | NEMA 3S | IP54 | ||||||
| Operating Altitude | 2000m | |||||||
| Operating Temperature | -22℉~122℉ (-30℃~50℃) | |||||||
| Relative Humidity | ≤95% | |||||||
| IK Level | IK10, Except screen | |||||||
| Installation Mode | Floor-standing | |||||||
| Cable Length | 5m | |||||||
| Size (H*W*D) | 79.17X46.85X34.25" / 2011X1190X870mm | |||||||
| Net Weight | 500kg | 550kg | 700kg | |||||
| HMI & Startup Method | ||||||||
| Charging Method | Standard: Swipe RFID card (offline), Plug and charge, VIN Optional: Swipe RFID card (online), Scan QR code |
|||||||
| Connectivity | Standard: LAN, WiFi Optional: 4G |
|||||||
| Indicator Light | Two-color indicator, Standby: Green light always on, Charging: Green light flashes, Fault: Red light always on. | |||||||
| Display Screen | 10-inch touch screen | |||||||
| Advertising Screen | LCD (55-inch 3840*2160 touch screen) | |||||||
| Communication Protocol | OCPP 1.6J | |||||||
| Auto Cable Management | Yes | |||||||
