Flexible and High-efficiency Current Output
• Delivers up to 80A high current in single-gun mode, enhancing single-vehicle charging efficiency
• Provides balanced 40A output in dual-gun mode, meeting simultaneous charging needs for two vehicles.
Compact Structural Design
• Precision-optimized body layout significantly reduces size while ensuring full functionality, saving installation space for versatile applications.
Quick and Easy Installation
• Simplified mounting structure and integrated wiring interfaces reduce construction complexity and shorten installation time, enabling rapid deployment.
| Parameter | Double plug | Single Plug |
| Power Rating | 9.6kW*2 | 19.2kW |
| Input/output Voltage | 208V (±15%), 240V (±15%), 60Hz | |
| Max. Output Current | 40A*2 | 80A |
| Connector Type | SAE J1772 / NACS 7.5m(25') or 5m(17') | |
| Network Type | 11/1/2/PE, 11/N/PE | |
| Input Cord | Hardwired | |
| Ground Fault Detection | 20mA CCID | |
| Enclosure Rating | Type 4 | |
| Card Reader | ISO14443A/B | |
| Operating Temperature | -22℉~131℉ (-30℃~55℃) | |
| Storage Temperature | -40℉~176℉ (-40℃~80℃) | |
| Operating Altitude | 2000m | |
| Installation Mode | Wall or floor using a pedestal | |
| Number of Outputs | 2 (line length 7.5m) | |
| Size (H*W*D) | 20.2X13.9X5.7" / 513X353X145mm | |
| HMI & Startup Method | ||
| Charging Method | APP, RFID | |
| Connectivity | 4G, Wi-Fi, Ethernet | |
| Communication Protocol | OCPP 2.0.1 (OCPP 1.6J optional) | |
| Status Indication | LCD (7-inch 800*480 touch screen) | |
| EMC Compliance | FCC 15 Class B | |
| Protection | Overcurrent, Overvoltage, Undervoltage, Overtemperature, Integrated surge protection | |
