| Parameter | US | EU | ||||
| Product Power | 120kW | 180kW | 240kW | 120kW | 180kW | 240kW |
| Input Voltage | 3-phase 480V AC (+10%/-15%) 60Hz | 3-phase 400V AC (+10%/-10%) 50Hz | ||||
| Input Current | 155A | 233A | 310A | 186A | 279A | 372A |
| Output Voltage | 200-1000VDC | |||||
| Max Output Current | 200A | 250A | ||||
| Number of Outputs | 2 | |||||
| Interface Type | CCS1, NACS | CCS2 | ||||
| Input Wire Harness | 3P+PE, 3P+N+PE | |||||
| Protection Level | NEMA 3S | IP54 | ||||
| Operating Altitude | 2000m | |||||
| Operating Temperature | -22℉~122℉ (-30℃~50℃) | |||||
| Relative Humidity | ≤95% | |||||
| IK Level | IK10, Except screen | |||||
| Installation Mode | Floor-standing | |||||
| Cable Length | 5m | |||||
| Size (H*W*D) | 92.9X38.6X33.3" / 2360X980X845mm | |||||
| Net Weight | 606kg | 648kg | 690kg | |||
| HMI & Startup Method | ||||||
| Charging Method | Standard: Swipe RFID card (offline), Plug and charge, VIN Optional: Swipe RFID card (online), Scan QR code |
|||||
| Connectivity | Standard: LAN, WiFi Optional: 4G |
|||||
| Indicator Light | Two-color indicator, Standby: Green light always on, Charging: Green light flashes, Fault: Red light always on. | |||||
| Display Screen | 10-inch touch screen | |||||
| Advertising Screen | LCD (55-inch 3840*2160 touch screen) | |||||
| Communication Protocol | OCPP 1.6J | |||||
| Auto Cable Management | Yes | |||||
