Convenient Operation
• Supports RFID card, Password charge and Plug & Charge, and features an LED display for real-time monitoring of charging status, power usage, and cost.
Universal Compatibility
• Fits most mainstream EV connectors, enabling quick deployment for private homes, residential communities, and public spaces like shopping malls.
Safe & Reliable
• Equipped with multiple protections against overvoltage, overcurrent, leakage, and short circuits, with real-time status monitoring to ensure charging safety
| Parameter | US | EU | |||
| Product Power | 1.9.2kW*2 | 7kW | 7kW*2 | ||
| Input Voltage | 120 - 240Vac(±10%), 60Hz | 230Vac(±10%), 50Hz | |||
| Max. Output Current | 80A*2 | 32A | 32A*2 | ||
| Interface Type | SAE J1 772 / NACS | Type 2 | |||
| Input Wire Harness | Three Lines-L1, L2, Earth wire | L, N, PE | |||
| Protection Level | NEMA 3S | IP54 | |||
| Operating Temperature | -22℉~122℉ (-30℃~50℃) | ||||
| Relative Humidity | ≤95% | ||||
| Operating Altitude | 2000m | ||||
| IK Level | IK10 | ||||
| Operating Environment | Outdoor (with canopy), Indoor | ||||
| Usage Occasion | Residential and Commercial Charging | ||||
| Installation Mode | Floor-standing | ||||
| Number Of Interfaces | 2 (line length 7.5m) | ||||
| Size (H*W*D) | 63.0X19.7X9.8" / 1600X500X250mm | ||||
| Net Weight | 50kg | ||||
| HMI & Startup Method | |||||
| Charging Method | Standard: Swipe RFID card (offline), Password charge, Plug and charge Optional: Swipe RFID card (online), APP code scanning (online), POS machine |
||||
| Connectivity | Standard: LAN, WiFi Optional: 4G |
||||
| Indicator Light | Two-color indicator, Standby: Green light always on, Charging: Green light flashes, Fault: Red light always on. | ||||
| Display Screen | 7-inch touch screen | ||||
| Advertising Screen | LCD (21.5-inch 1920*1080 touch screen) | ||||
| Communication Protocol | OCPP 1.6J | ||||
| Auto Cable Management | Yes | ||||
