| Parameter | US | EU | |||
| Product Power | 11.5kW*2 | 7kW*2 | 11kW*2 | 22kW*2 | |
| Input Voltage | 120 - 240Vac(±10%), 60Hz | 230Vac(±10%), 50Hz | |||
| Max. Output Current | 48A*2 | 32A | 16A | 32A | |
| Interface Type | SAE J1 772 / NACS | Type 2 | |||
| Input Wire Harness | L1, N/L2, PE | L, N, PE | L1, L2, L3, PE | ||
| Protection Level | NEMA 3S | IP54 | |||
| Operating Temperature | -22℉~122℉ (-30℃~50℃) | ||||
| Relative Humidity | ≤95% | ||||
| Operating Altitude | 2000m | ||||
| IK Level | IK10 | ||||
| Operating Environment | Outdoor (with canopy), Indoor | ||||
| Usage Occasion | Residential and Commercial Charging | ||||
| Installation Mode | Floor-standing | ||||
| Number of Outputs | 2 (line length 7.5m) | ||||
| Size (H*W*D) | 68.9X8.9X7.1" / 1750X250X180mm | ||||
| Net Weight | 70kg | ||||
| HMI & Startup Method | |||||
| Charging Method | Standard: Swipe RFID card (offline), Password charge, Plug and charge Optional: Swipe RFID card (online), APP code scanning (online), POS machine |
||||
| Connectivity | Standard: LAN, WiFi, OCPP1.6J Optional: 4G |
||||
| Indicator Light | Two-color indicator, Standby: Green light always on, Charging: Green light flashes, Fault: Red light always on. | ||||
| Display Screen | 4.3-inch touch screen | ||||
| Auto Cable Management | Yes | ||||
