Flexible Deployment
• Breaks the limitations of fixed EV chargers, enabling rapid deployment and relocation..
• Addresses common charging challenges including occupied spots and low-power situations, extending your journey with reliable power wherever you go.
Energy Storage Power Supply
• Features a high-capacity battery to store and supply power independently, operating fully off-grid.
Emergency Backup
• Provides emergency power during grid outages or vehicle failures, ensuring critical energy for rescue or stranded vehicles to maintain mobility
| AC Input EU | |
| Input Voltage | 3-phase 400V AC (+10%/-10%) 50Hz |
| Power Factor | ≥0.99 |
| Total Harmonic Distortion | <5% |
| Overvoltage Category | AC side (Input) OVC: Ⅲ |
| DC Output | |
| Output Power | 40kW |
| Output Voltage | 200 - 1000VDC |
| Output Current | 133A |
| Peak Efficiency | ≥95.5% |
| Charging Mode | CCS2*1 |
| AC Output | |
| Max. Output Power | 30kW |
| Output Voltage | 380V AC/ 220V AC |
| Number of Outputs | 380V AC (45A*1), 220V AC(26A*1) |
| Output Terminal | Industrial Quick Plug |
| User Interface | |
| RFID Protocol | ISO 14443 A/B |
| Communication Protocols | OCPP 2.0.1(OCPP 1.6J optional) |
| Charging Method | QR Code, RFID |
| General Specification | |
| Battery Capacity | 30kWh, 60kWh |
| Screen Type | LCD (10.1-inch 1920*1080 touch screen) |
| Connectivity | 4G, Wi-Fi, Ethernet |
| Cable Length | 5m |
| Standby Power | 40W |
| Enclosure Rating | IP54, IK10 |
| Communication to EV | ISO/IEC 15118, DIN 70121 |
| Operating Altitude | 2000m |
| Operating Temperature | 32°F~122°F (0℃~50℃) |
| Storage Temperature | -22°F~140°F (-30℃~60℃) |
| Noise | ≤60dB |
| Size (L*W*H) | 81.7x47.2x46.8"/2075x1200x1190 mm (Without wheels) 81.7x68.1x74.0"/2075x1730x1880 mm (With wheels) |
