Ultra-fast Charging
• Supports 600A (Max.800A) continuous output, compatible with high-voltage platform vehicles for ultra-fast charging needs, significantly reducing charging time.
Liquid-cooling Tech
• Utilizes active liquid-cooling technology for precise temperature control, ensuring sustained high-power output while enhancing safety and lifespan.
Intelligent Safety Protection
• Integrates multi-level safeguards (over-temperature, over-current, etc.) and supports mainstream charging standards (CCS1/CCS2/NACS), enabling efficient compatibility and optimized charging for diverse vehicle models.
| Parameter | US | EU | ||
| Product Power | 320kW | 480kW | 320kW | 480kW |
| Input Voltage | 3-phase 480V AC (+10%/-15%) 60Hz | 3-phase 400V AC (+10%/-10%) 50Hz | ||
| Input Current | 516A | 620A | 620A | 744A |
| Output Voltage | 200 - 1000VD | |||
| Output Current | 600A (Max:800A) | |||
| Number of Outputs | 2 | |||
| Interface Type | CCS1, NACS | CCS2 | ||
| Input Wire Harness | 3P+PE, 3P+N+PE | |||
| Protection Level | NEMA 3S | IP54 | ||
| Operating Altitude | 2000m | |||
| Operating Temperature | ≤22°F~122°F (-30℃~50℃) | |||
| Relative Humidity | ≤95% | |||
| IK Level | IK10, Except screen | |||
| Installation Mode | Floor-standing | |||
| Cable Length | 5m | |||
| Size (H*W*D) | 92.48X47.36X42.95" / 2349X1203X1091mm | |||
| Net Weight | 980kg | 1100kg | ||
| HMI & Startup Method | ||||
| Charging Method | Standard: Swipe RFID Card (offline), Plug and Charge Optional: Swipe RFID Card (online), Scan QR Code |
|||
| Connectivity | Standard: LAN, WiFi Optional: 4G |
|||
| Indicator Light | Two-color indicator, Standby: Green light always on, Charging: Green light flashes, Fault: The red light always on. | |||
| Display Screen | 10-inch touch screen | |||
| Advertising Screen | LCD (55-inch 3840*2160 touch screen) | |||
| Communication Protocol | OCPP 2.0.1 | |||
| Auto Cable Management | Yes | |||
